This AVR-series uses advanced control technology made with reliable components. It is a new type of AC automatic regulator with automatic control system. It has the features of wide input voltage range, high reliability, better stabilized output voltage, energy saving, etc.
Applications
It can be used to supply stabilized power to lights, Television, refrigerator, computer and duplicating machine and other household equipment; School, Office, Hotel, etc
Features
- Input And Output Display
- Over Voltage Protection
- Over Load Protection
- Low Output Voltage Protection
- High Output Voltage Protection
- High Temperature Protection
- Wide input voltage range (Super Low model also available)
- Over-voltage, Low –voltage, delayed output, short circuit and High temperature protection
- Classic series, EI transformer, relay type
- Input and output voltage meter display
- Circuit breaker
- Efficiency: 98%
- VA Rating : 1000VA
TECHNICAL DETAILS (1000VA)
INPUT
- Phase: Single phase + N+ GND
- Voltage Range: 100VAC-260VAC (Super low voltage range also available)
OUTPUT
- Voltage Range: 200-240V(Empty load)
- Frequency: 50/60Hz
- Over voltage protection: 250V+5V (Over voltage indicator lights without output
- Under-voltage protection: 100V+5V (Under-voltage indicator lights without output)(not applicable to super low options)
SYSTEM
- Efficiency: 95%
- Display Mode: LED indicator light; Pointer voltmeter/LCD display
- Input/Output setting: Plug/Socket
- Wave Distortion: No additional waveform distortion
- Insulation Resistance: >2M
- Dielectric Strength: Low frequency sine voltage 1500V for 1 minute (without phenomena of breakdown and flashover)
- Ambient Temperature: -10 degree C – 40 degree C
- Relative Humidity: 95%
- Working: continuous
OTHERS
- Dimension (DxWxH)mm: 265x125x155
- Net weight (kg): 4.65
- Packing Dimension(DxWxH)mm: 300x200x210
- Gross weight (kg): 5
